Auto Glue Dispenser Wholesale - Xiaomao Machine-2
Product details of the auto glue dispenser
Product Description
While producing Xiaomao Machine auto glue dispenser, every manufacturing machine is strictly checked before starting. The materials used have determined the durability and performance of this product. Shenzhen Xiaomao Automation Technology Co.Ltd requires more than a dozen inspections of raw materials from the factory to the finished product.
Model | Automatic dispensing machine | |
Working range X/Y/Z (mm) | 300*300*100/500*300*300*100 Customizable stroke | |
Programming method | Teaching programming or graphic import | |
Moving graphic trajectory | Point, straight line, arc, full circle, curve, polyline, spiral, ellipse | |
Dispensing needle | Plastic steel needle, TT needle | |
Dispensing cylinder | 30CC/50CC/100CC/200CC/300CC/500CC | |
Minimum discharge volume (mm) | 0.01 | |
Dispensing frequency (times/second) | 5 | |
Load (kg)
| X/Y axis | 10 |
Z axis | 5 | |
Weight (kg) | 48 | |
Motion system | Nihono stepper motor, driver | |
Operating system | LCD panel/handheld programmer | |
Repeat positioning accuracy (mm) | Screw drive | ±0.01-0.02 |
Synchronous belt | ±0.02-0.04 | |
Machine size (MM) | 540*580*650 | |
Program storage capacity | 999 parameter files (65,535 points per file) | |
Transmission method | Upper silver rail (slider) | |
Maximum speed (mm/s) | 300 | |
Marketing type | Ordinary product | |
Showroom location | Germany | |
Health condition | New | |
Warranty | 1 year | |
Core component warranty | 1 year | |
Mechanical test report | Provided | |
Video shipment inspection | Provided | |
Origin | Guangdong, China | |
Core components | PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump | |
Applicable glue | UV glue, AB glue, black glue, white glue, yellow glue, EMI conductive glue, anaerobic glue, epoxy resin, instant glue, silver glue, red glue, solder paste, heat dissipation paste, solder mask, transparent paint, lubricating oil, flux, screw fixing agent, etc. | |
Applicable products
| Sensors, relays, power adapters, electronic toys, buzzers, electronic components, household appliances, toys, stationery, electric vehicle controllers, computer digital products, handicrafts, mobile phone boards, coil products, key products, battery boxes, speaker outer ring dispensing and bonding, etc | |
Applicable industries | hotels, clothing stores, building materials stores, manufacturing plants, machinery repair shops, food and beverage factories, farms, restaurants, home use, retail, food stores, printing shops, construction projects, energy and mining, food and beverage stores, advertising companies, etc | |
FAQ
Company Advantage
• Xiaomao Machine has a scientific management mode and great production capability. We carry out standard and scale production, so as to ensure that we could meet customers' needs for large-quantity orders of quality machinery. We can provide custom services.
• Xiaomao Machine insists on the service concept that we put customers first. We are committed to providing one-stop services.
• Having developed rapidly for years, Xiaomao Machine is a machinery manufacturer with a relatively large scale and great business capability.
• Our products occupy a certain market share in domestic and foreign regions.
• Reasonable in design, stable in operation, convenient in operation and reliable in quality, the mechanical equipment produced by Xiaomao Machine has a long product life.
Large margin sales are going on. The more you buy, the more cost-effective price you will get. For details, please consult Xiaomao Machine.
