Auto Glue Dispenser - - Xiaomao Machine-7

Company Advantages

· Xiaomao Machine become more famous mainly for its independent designs.

· Its quality has been well controlled by strictly conducting quality control system.

· It turns out to be true that with the professional service, more and more customers will keep Xiaomao Machine in mind.

Model		Automatic dispensing machine
Working range X/Y/Z (mm)		300*300*100/500*300*300*100 Customizable stroke
Programming method		Teaching programming or graphic import
Moving graphic trajectory		Point, straight line, arc, full circle, curve, polyline, spiral, ellipse
Dispensing needle		Plastic steel needle, TT needle
Dispensing cylinder		30CC/50CC/100CC/200CC/300CC/500CC
Minimum discharge volume (mm)		0.01
Dispensing frequency (times/second)		5
Load (kg)	X/Y axis	10
	Z axis	5
Weight (kg)		48
Motion system		Nihono stepper motor, driver
Operating system		LCD panel/handheld programmer
Repeat positioning accuracy (mm)	Screw drive	±0.01-0.02
	Synchronous belt	±0.02-0.04
Machine size (MM)		540*580*650
Program storage capacity		999 parameter files (65,535 points per file)
Transmission method		Upper silver rail (slider)
Maximum speed (mm/s)		300
Marketing type		Ordinary product
Showroom location		Germany
Health condition		New
Warranty		1 year
Core component warranty		1 year
Mechanical test report		Provided
Video shipment inspection		Provided
Origin		Guangdong, China
Core components		PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump
Applicable glue		UV glue, AB glue, black glue, white glue, yellow glue, EMI conductive glue, anaerobic glue, epoxy resin, instant glue, silver glue, red glue, solder paste, heat dissipation paste, solder mask, transparent paint, lubricating oil, flux, screw fixing agent, etc.
Applicable products		Sensors, relays, power adapters, electronic toys, buzzers, electronic components, household appliances, toys, stationery, electric vehicle controllers, computer digital products, handicrafts, mobile phone boards, coil products, key products, battery boxes, speaker outer ring dispensing and bonding, etc
Applicable industries		hotels, clothing stores, building materials stores, manufacturing plants, machinery repair shops, food and beverage factories, farms, restaurants, home use, retail, food stores, printing shops, construction projects, energy and mining, food and beverage stores, advertising companies, etc

Products Description

Company Features

· Shenzhen Xiaomao Automation Technology Co.Ltd grows rapidly in auto glue dispenser field with superior quality.

· Thanks to the advance technology, Shenzhen Xiaomao Automation Technology Co.Ltd greatly increases the output of auto glue dispenser. The technical strength of Shenzhen Xiaomao Automation Technology Co.Ltd greatly has improved the efficiency of auto glue dispenser production.

· We insist on the principle of "quality and innovation first". We will develop more quality products to meet the customers’ requirements and seek valuable feedback from them.

Product Details

Our auto glue dispenser are processed by the latest technology in the industry, and they perform better in the following details.

Product Comparison

Compared with similar products, our company's auto glue dispenser has the following outstanding features.

Enterprise Advantages

Xiaomao Machine's excellent team consists of a group of talents with a great education background, rich experience, and strong technical capability.

Xiaomao Machine runs a comprehensive product supply and after-sales service system. We are committed to providing thoughtful services for customers, so as to develop their greater sense of trust for the company.

To pay back to society with the first-class products and service, we will, as always, adhere to the corporate strategy of 'science and technology, talent support, brand driving, and cultural development', the spirit of 'profession, innovation, integrity and responsibility' and the tenet of 'serving customers and benefiting the society'.

Xiaomao Machine was built in Having developed the business for years, we are now a leading enterprise in the industry. We are equipped with advanced production equipment and strong technical capability.

Our sales network has basically covered all major cities in the country. In addition, our products are also exported to Southeast Asia, the Middle East, South America and other overseas regions.
