Automated Glue Dispenser by Xiaomao Machine-4
Model | Automatic dispensing machine | |
Working range X/Y/Z (mm) | 300*300*100/500*300*300*100 Customizable stroke | |
Programming method | Teaching programming or graphic import | |
Moving graphic trajectory | Point, straight line, arc, full circle, curve, polyline, spiral, ellipse | |
Dispensing needle | Plastic steel needle, TT needle | |
Dispensing cylinder | 30CC/50CC/100CC/200CC/300CC/500CC | |
Minimum discharge volume (mm) | 0.01 | |
Dispensing frequency (times/second) | 5 | |
Load (kg)
| X/Y axis | 10 |
Z axis | 5 | |
Weight (kg) | 48 | |
Motion system | Nihono stepper motor, driver | |
Operating system | LCD panel/handheld programmer | |
Repeat positioning accuracy (mm) | Screw drive | ±0.01-0.02 |
Synchronous belt | ±0.02-0.04 | |
Machine size (MM) | 540*580*650 | |
Program storage capacity | 999 parameter files (65,535 points per file) | |
Transmission method | Upper silver rail (slider) | |
Maximum speed (mm/s) | 300 | |
Marketing type | Ordinary product | |
Showroom location | Germany | |
Health condition | New | |
Warranty | 1 year | |
Core component warranty | 1 year | |
Mechanical test report | Provided | |
Video shipment inspection | Provided | |
Origin | Guangdong, China | |
Core components | PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump | |
Applicable glue | UV glue, AB glue, black glue, white glue, yellow glue, EMI conductive glue, anaerobic glue, epoxy resin, instant glue, silver glue, red glue, solder paste, heat dissipation paste, solder mask, transparent paint, lubricating oil, flux, screw fixing agent, etc. | |
Applicable products
| Sensors, relays, power adapters, electronic toys, buzzers, electronic components, household appliances, toys, stationery, electric vehicle controllers, computer digital products, handicrafts, mobile phone boards, coil products, key products, battery boxes, speaker outer ring dispensing and bonding, etc | |
Applicable industries | hotels, clothing stores, building materials stores, manufacturing plants, machinery repair shops, food and beverage factories, farms, restaurants, home use, retail, food stores, printing shops, construction projects, energy and mining, food and beverage stores, advertising companies, etc | |
FAQ
Company Advantages
· What calls for customers' attention is that our automated glue dispenser is produced by skillful manufacture.
· The product is tested by different standards testing institutions at home and abroad.
· Taking an innovative approach based on scientific research, Xiaomao Machine is able to develop automated glue dispenser and enhance its performance.
Company Features
· With constant innovation, Shenzhen Xiaomao Automation Technology Co.Ltd is in leading status of international automated glue dispenser market.
· The factory has implemented a strict QC process system. This system includes preliminary inspection (ensuring the quality of the raw materials), in-process quality control (ensuring machining quality), and output quality control of finished products (testing on the performance and reliability).
· Reputation and good credit are the eternal goals of Shenzhen Xiaomao Automation Technology Co.Ltd. Please contact us!
Application of the Product
automated glue dispenser of Xiaomao Machine has very extensive application in different scenarios.
From the customer's point of view, we provide our customers with a complete, fast, efficient and feasible solution to solve their problems.
