Automated Glue Dispensing Systems - - Xiaomao Machine-5

Product details of the automated glue dispensing systems

Quick Overview

Xiaomao Machine's Automatic soldering machine,automatic glue dispensing machine,automatic screw locking machine have reasonable structure, novel design, and reliable quality. With a small noise, they are easy to operate and are stable during the operation. The distinctive design of Xiaomao Machine automated glue dispensing systems comes from our professional design team. Excellent performance and long service life make the product competitive. With product quality as the center, Shenzhen Xiaomao Automation Technology Co.Ltd insists on the spirit of independent innovation.

Product Description

Xiaomao Machine adheres to the principle of 'details determine success or failure' and pays great attention to the details of automated glue dispensing systems.

Model		Automatic dispensing machine
Working range X/Y/Z (mm)		300*300*100/500*300*300*100 Customizable stroke
Programming method		Teaching programming or graphic import
Moving graphic trajectory		Point, straight line, arc, full circle, curve, polyline, spiral, ellipse
Dispensing needle		Plastic steel needle, TT needle
Dispensing cylinder		30CC/50CC/100CC/200CC/300CC/500CC
Minimum discharge volume (mm)		0.01
Dispensing frequency (times/second)		5
Load (kg)	X/Y axis	10
	Z axis	5
Weight (kg)		48
Motion system		Nihono stepper motor, driver
Operating system		LCD panel/handheld programmer
Repeat positioning accuracy (mm)	Screw drive	±0.01-0.02
	Synchronous belt	±0.02-0.04
Machine size (MM)		540*580*650
Program storage capacity		999 parameter files (65,535 points per file)
Transmission method		Upper silver rail (slider)
Maximum speed (mm/s)		300
Marketing type		Ordinary product
Showroom location		Germany
Health condition		New
Warranty		1 year
Core component warranty		1 year
Mechanical test report		Provided
Video shipment inspection		Provided
Origin		Guangdong, China
Core components		PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump
Applicable glue		UV glue, AB glue, black glue, white glue, yellow glue, EMI conductive glue, anaerobic glue, epoxy resin, instant glue, silver glue, red glue, solder paste, heat dissipation paste, solder mask, transparent paint, lubricating oil, flux, screw fixing agent, etc.
Applicable products		Sensors, relays, power adapters, electronic toys, buzzers, electronic components, household appliances, toys, stationery, electric vehicle controllers, computer digital products, handicrafts, mobile phone boards, coil products, key products, battery boxes, speaker outer ring dispensing and bonding, etc
Applicable industries		hotels, clothing stores, building materials stores, manufacturing plants, machinery repair shops, food and beverage factories, farms, restaurants, home use, retail, food stores, printing shops, construction projects, energy and mining, food and beverage stores, advertising companies, etc

Products Description

Company Introduction

Shenzhen Xiaomao Automation Technology Co.Ltd is a new type of company in The main business is focused on Automatic soldering machine,automatic glue dispensing machine,automatic screw locking machine. Xiaomao Machine always adheres to people-oriented business. We are honest and law-abiding in the development, with the aim to gain mutual benefit. We also promote the enterprise spirit of 'compete fairly, progress actively, advance promptly'. Based on the equality and mutual benefit, we partner with other outstanding enterprises in the industry and complement with each other. Together we can further promote the industry. Xiaomao Machine has a development team with many years of technical experience, and the team members have strong industrial logic thinking and industry experience, providing a strong guarantee for our development. Our solutions are developed by understanding the customer's situation and combining the current market conditions. Therefore, they are all targeted and can effectively solve problems of customers.
Xiaomao Machine's Automatic soldering machine,automatic glue dispensing machine,automatic screw locking machine are available in multiple types and in reliable quality. Feel free to contact us!
