Automatic Glue Dispenser Wholesale - Xiaomao Machine-7
Company Advantages
· The raw materials of Xiaomao Machine automatic glue dispenser are in conformity with the industry quality standards.
· We have strict quality control procedures to ensure the product goes to customers functioning safely and competitively.
· The product is full of economic benefits, bringing considerable profits to customers.
Model | Automatic dispensing machine | |
Working range X/Y/Z (mm) | 300*300*100/500*300*300*100 Customizable stroke | |
Programming method | Teaching programming or graphic import | |
Moving graphic trajectory | Point, straight line, arc, full circle, curve, polyline, spiral, ellipse | |
Dispensing needle | Plastic steel needle, TT needle | |
Dispensing cylinder | 30CC/50CC/100CC/200CC/300CC/500CC | |
Minimum discharge volume (mm) | 0.01 | |
Dispensing frequency (times/second) | 5 | |
Load (kg)
| X/Y axis | 10 |
Z axis | 5 | |
Weight (kg) | 48 | |
Motion system | Nihono stepper motor, driver | |
Operating system | LCD panel/handheld programmer | |
Repeat positioning accuracy (mm) | Screw drive | ±0.01-0.02 |
Synchronous belt | ±0.02-0.04 | |
Machine size (MM) | 540*580*650 | |
Program storage capacity | 999 parameter files (65,535 points per file) | |
Transmission method | Upper silver rail (slider) | |
Maximum speed (mm/s) | 300 | |
Marketing type | Ordinary product | |
Showroom location | Germany | |
Health condition | New | |
Warranty | 1 year | |
Core component warranty | 1 year | |
Mechanical test report | Provided | |
Video shipment inspection | Provided | |
Origin | Guangdong, China | |
Core components | PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump | |
Applicable glue | UV glue, AB glue, black glue, white glue, yellow glue, EMI conductive glue, anaerobic glue, epoxy resin, instant glue, silver glue, red glue, solder paste, heat dissipation paste, solder mask, transparent paint, lubricating oil, flux, screw fixing agent, etc. | |
Applicable products
| Sensors, relays, power adapters, electronic toys, buzzers, electronic components, household appliances, toys, stationery, electric vehicle controllers, computer digital products, handicrafts, mobile phone boards, coil products, key products, battery boxes, speaker outer ring dispensing and bonding, etc | |
Applicable industries | hotels, clothing stores, building materials stores, manufacturing plants, machinery repair shops, food and beverage factories, farms, restaurants, home use, retail, food stores, printing shops, construction projects, energy and mining, food and beverage stores, advertising companies, etc | |
FAQ
Company Features
· We are a company specializing in the manufacture of a wide variety of automatic glue dispenser in the global market.
· Produced by the continuously developing innovative technologies, the quality of automatic glue dispenser has become more competitive in this industry.
· Xiaomao Machine's mission is to offer the best automatic glue dispenser for customers. Inquire now!
Enterprise Advantages
Our company's R&D team has rich experience and excellent technical capabilities. With the constant focus on the research of product innovation, they have made major breakthroughs. And it has laid a solid foundation for our sustainable development.
To provide faster and better service, our company constantly improves the service quality and promotes the service personnel level.
Xiaomao Machine is an enterprise full of vitality and flourishing. We firmly believe that tomorrow would surely be better as long as we are market-oriented, innovation-driven, quality-seeking and development-oriented.
Since the establishment in Xiaomao Machine has been engaged in the business of Automatic soldering machine,automatic glue dispensing machine,automatic screw locking machine. We have accumulated rich industry experience during the development for years.
The excellent quality of our company's products brings a wide range of customers sources and has attracted a large number of customers from overseas to purchase.
